MACHINE MAIN TECHNICAL PARAMETERS
| MODEL | JZ32 |
| Max.Drilling Capacity | 32mm |
| Diameter of column | 102mm |
| Spindle stroke | 130mm |
| Distance spindle axis to column surface | 230mm |
| Max. distance spindle nose to worktable | 620mm |
| Max. distance spindle nose to base | 1095mm |
| Spindle taper | MT.3 |
| Spindle speeds range | 160-1880rpm |
| Number of spindle speeds | 9 |
| Dimension of worktable surface | Ø420mm/380✖330mm |
| Dimension of workbench surface | 300×320mm |
| Motor | 1100W/六极 |
| G.W/N.W | 220/200kg / 230/210kg |
| Ship measurement | 930×570×1800mm |
