| MODEL | Z5040（L） | Z5045（L） |
| Max.Drilling Capacity | 31.5mm | 45mm |
| Diameter of column | 115mm | 115mm |
| Spindle stroke | 120mm | 120mm |
| Distance spindle axis to column surface | 272.5mm | 272.5mm |
| Max. distance spindle nose to worktable | 835mm | 820mm |
| Max. distance spindle nose to base | 1300mm | 1285mm |
| Spindle taper | MT.3 | MT.4 |
| Spindle speeds range | 85-1445rpm | 85-1445rpm |
| Number of spindle speeds | 8 | 8 |
| Dimension of worktable surface | 540×470mm | 540×470mm |
| Dimension of workbench surface | 400×310mm | 400×310mm |
| Motor | 双速850W/1100W | 双速850W/1100W |
| G.W/N.W | 345/305kg | |
| Ship measurement | 84×740×1930mm | |
Note: "L" - equipped with a cooling device, to be purchased by the customer
