| MODEL | SWJ-12 |
| Max. Tapping Capacity | M12/M8 |
| Diameter of column | 60mm |
| Spindle stroke | 45mm |
| Distance spindle axis to column surface | 127mm |
| Max. distance spindle nose to worktable | 290mm |
| Max. distance spindle nose to base | 380mm |
| Spindle taper | B16 |
| Spindle speeds range | 正：260,440,750 反：320,550,930 |
| Dimension of worktable surface | 230×230mm |
| Dimension of workbench surface | 180×200mm |
| Motor | 550W |
| G.W/N.W | 61/54kg |
| Ship measurement | 610×440×910mm |
