| 型 号 | MODEL | ZX-40BHC(L) | ZX-45BHC(L) |
| 最大钻孔直径 | Max.Drilling Capacity | 31.5mm | 45mm |
| 最大端铣宽度 | Max.Face mill Capacity | 80mm | 80mm |
| 最大立铣宽度 | Max.End mill Capacity | 28mm | 28mm |
| 立柱直径 | Diameter of column | 115mm | 115mm |
| 主轴最大行程 | Spindle stroke | 120mm | 120mm |
| 主轴中心线至立柱表面距离 | Distance spindle axis to column surface | 252.5mm | 252.5mm |
| 主轴端至工作台最大距离 | Max. distance spindle nose to worktable | 785mm | 785mm |
| 主轴端至底座最大距离 | Max. distance spindle nose to base | 1300mm | 1300mm |
| 主轴锥度 | Spindle taper | MT.3 | MT.4 |
| 主轴转速范围 | Spindle speeds range | 85-1445rpm | 85-1445rpm |
| 主轴转速级数 | Number of spindle speeds | 8 | 8 |
| 工作台面尺寸 | Dimension of worktable surface | 585×190mm | 585×190mm |
| 工作台行程 | Travel of worktable | 370×145mm | 370×145mm |
| 电机功率 | Motor | 双速850W/1100W | 双速850W/1100W |
| 毛重/净重 | G.W/N.W | 345/305kg | 350/310kg |
| 包装尺寸﹙长×宽×高 | Ship measurement | 900×800×1930mm | 900×800×1930mm |
